Flotation machine can be used for many ore beneficiation . It is subject to coarse separation, swept separation, fine separation and flotation, so the useful ore are reclaimed.
1. Mining flotation machines mainly includes mechanical agitation flotation machines, and inflatable agitation flotation machines
2. The mechanical agitation flotation machine mainly relies on the mechanical agitator (rotor and stator) to realize the aeration and stirring of the ore pulp, which belongs to the air self-priming flotation machine. It does not need an external gas filling device, and it does not need a pump to transport the middle ore back, and it can realize self-flow. The SF series mechanical agitation flotation machine is mainly used in mineral processing plants. SF type mechanical agitation flotation machine has a wide range of applications and is suitable for metal and non-metal minerals. It is mostly used for roughing and sweeping operations in medium and large beneficiation plant.
3. The inflatable agitation flotation machine mainly relies on the rotation of the mechanical agitator to stir the pulp, and uses the blower to realize the aeration, which belongs to the external air supply flotation machine. The XCF inflatable agitated flotation cell is mainly used in mineral processing plants, and it is used in medium and large mineral processing plants for roughing and sweeping operations.
The above is the flotation machine equipment commonly used in mineral processing plants. As for the choice of suitable flotation equipment, it is necessary to make targeted selection according to the characteristics of raw mineral (ore density, particle size, mud content, grade, floatability) and so on. The appropriate flotation machine is selected scientifically and reasonably to improve the production efficiency of dressing plant.
Simple structure, strong agitation ability, and low energy consumption.
The air scattering is uniform and the mixing effect of air and slurry is good.
The impeller is equipped with holey cylinder air alloter.
Solid particles can be fully suspended, high flotation index.
When the flotation machine works, the motor drives the impeller to revolve, so the centrifugal effect and negative pressure are produced. On one hand, ample air is absorbed and mixed with mineral slurry, on the other hand, the mixed mineral slurry is mingled with additive, meanwhile, the foams are thinning, the mineral is bounded with foams, and floats up to the surface of mineral slurry and the mineralized foam is formed. The liquid surface can be adjusted with the height of adjustment flashboard, so that the useful foams are scraped with squeegee.
SF series Flotation Machine
| Model | SF0.37 | SF0.7 | SF1.2 | SF2.8 | SF4 | |
| Volume (m³) | 0.37 | 0.7 | 1.2 | 2.8 | 4 | |
| Impeller diameter（mm） | 300 | 350 | 450 | 550 | 650 | |
| Capacity (m³/min) | 0.2-0.4 | 0.3-0.9 | 0.6-1.2 | 1.5-3.5 | 0.5-4 | |
| Impeller Speed(r/min) | 352 | 400 | 312 | 268 | 238 | |
| Impeller motor | Model | Y90L-4 | Y100L2-4 | Y132M2-6 | Y160L-6 | Y180L-6 |
| Power (Kw) | 1.5 | 3 | 5.5 | 11 | 15 | |
| Scraper motor | Model | Y90S-4 | Y90L-4 | |||
| Power (Kw) | 1.1 | 1.5 | ||||
XJK Series Flotation Machine
| Model | XJK-0.13(1A) | XJK-0.23(2A) | XJK-0.35(3A) | XJK-0.62(4A) | XJK-1.1(5A) | XJK-2.8(6A) | |
| Volume (m³) | 0.13 | 0.23 | 0.35 | 0.62 | 1.1 | 2.8 | |
| Impeller diameter（mm） | 200 | 250 | 300 | 350 | 500 | 600 | |
| Capacity (m³/min) | 0.05-0.16 | 0.12-0.28 | 0.18-0.4 | 0.3-0.9 | 0.6-1.6 | 1.5-3.5 | |
| Scraper Speed(r/min) | 17.5 | 17.5 | 17.5 | 26 | 26 | 26 | |
| Impeller motor | Model | Y100L1-4 | Y90L-4 | Y90L-4 | Y100L2-6 | Y132M2-6 | Y160L-6 |
| Power (Kw) | 2.2 | 1.5 | 1.5 | 3 | 5.5 | 11 | |
| Scraper motor | Model | Y80M1-4 | Y80M1-4 | Y80M2-4 | Y80M2-4 | Y90S-4 | Y90S-4 |
| Power (Kw) | 0.55 | 0.55 | 0.75 | 0.75 | 1.1 | 1.1 | |
*The output will vary according to different materials, feed particle size and other factors
