150-250tph Sand making plant

150-250tph Sand making plant introduction

Sand making plant is a special production line for producing sand and aggregate materials for construction. In the sand making plant, natural rocks, sandstones, river pebbles and other materials can be processed into artificial sand that meets the requirements of building sand, so as to replace the natural river sand for the buildings and construction industries that need high-quality aggregates. Any kind of material with different hardness grades such as limestone, basalt, granite, dolomite, gabro can be crushed. In addition to sand (fine materail) it is also possible to produce other 3 different final fractions simultaneously.

Features

1. Complete crushing and screening plant is consisting of one or several crushing and screening units based on the customers' needs.

2. This series of plant is used to crush rocks in the industries such as road construction, building construction, construction materials, water and electricity and civil building etc working with commercial concrete, dry mixed mortar and mixing plant.

3. Core equipment for manufactured sand production line is sand making machine such as vsi crusher, vsi5x crusher etc.

4. It is suitable for crushing high quality of basalt, diabase, granite, river gravel, limestone and other hard or medium hard rocks.

5. High production efficiency, regular end product granularity, good grain cubical sand, and low powder content.

How does 150-250tph Sand making plant Work?

1.Crush and screen process

Raw stone materials go to Jaw crusher for primary crushing. Then the materials are transferred by the belt conveyor to secondary crusher ( impact crusher or Cone crusher) for further crushing. Vibrating screen will grade the materials, where stones that meet the granularity standard will be sent to VSI crusher (sand-maker), while the rest will be returned to crush again. Materials that don’t meet the required particle size will be sent back to the sand maker for further process or as final aggregate products. In wet type, the screen could be add a water-spraying system to remove the impurities in advance.

2.Sand washing process

Part of the stones processed by VSI crusher (sand maker) will be made into sand and become sand products after being washed by sand washing machine and sand recycling machine. The sand washing machine could choose wheel type or spiral ty pe based on the site situation. Sand dewartering and recylcing machine is to help get fine sand and prevent sand loss. Filter machine and sand dryer is optional too according to demand. After the washing process, we get the finished products.

Our service

1. Dingli Group has 20+ years of experience in the sand crushing and screening plant. We are skilled in the production plant design and insists on providing customers with high yield, energy-saving and environmental protection rock crushers and other relative machines.

2. We provide overall solutions from equipment recommendation to debugging and installation, worker training, technical support and maintenance. The spares parts is provided all servide life.

3. Our machines have delivered to hundreds of countries, such as Indonesia, Philippines, Vietnam, Malaysia, India, Pakistan, Kenya, the USA, Ghana, Zimbabwe, America, Australia Canada, Peru, Columbia, Guatemala, Uzbekistan, Russia etc. The engineers are assigned to install and train in cusomter site.
