Jaw crusher is a kind of stone crusher machine which is widely used as primary or secondary crusher in stone crushing plant. The purpose is to reduce hard stone material to a small size that it can be transported by conveyors to the next crushing stages.
1.Model: Jaw crusher model depends on the size of the feeding port. Choosing suitable model is the main factor that buyers need to consider in the initial stage. The size of the model determines the production capacity range of stone crusher.
2.Feed port size: raw material size determines the size of jaw crusher feeding port. The larger the crushed material, the larger the size of jaw crusher feeding port. Large size stones need to choose a large-sized feed port to meet the production needs, and at the same time avoid troubles caused by inappropriate models.
3.Processing capacity: The processing capacity of jaw crushing machine is a key factor to purchase stone crusher. The output per hour is one of the reference factors. It determines the scale of stone production plant.
4.Motor power: The motor power is determined in combination with the overall size of stone crushers. If the equipment is large and the motor power is too small, it will definitely not be able to carry it. Choosing a reasonable electric power will help improve the production efficiency of jaw crusher.
In addition to meeting your own production needs, the appearance and configuration of stone crushing equipment, you also need to investigate and understand the production strength of stone crusher manufacturer. Henan Baichy Machinery Equipment Co., Ltd. is a high-tech enterprise integrating R&D, production, sales and service. The hot jaw crushers manufactured by our company can be further divided into four types: PE jaw crusher, PEX fine jaw crusher, C-series jaw crusher , SKJ jaw crusher and mobile jaw crusher.
Heavy-duty designed jaws crusher frame. High manganese steel castings jaw plate can be reversed to extend life and save cost. Gasket adjusting device is reliable and convenient.
Baichy jaw crusher machine could be made in mobile type crushing plant, or stationary primary crushing machine in mining and quarry plant.
Deep crushing chamber is to improve feeding and output capacity. Baichy jaw crusher is developed to crush hard stones in maximum productivity at the lowest operating costs. Wide adjustment range of discharging port meets different demands.
Baichy jaw crusher is for sale in Indonesia, Philiphines, Malaysia, Kenya, South Afica, Peru, Chile, Australia, Uzbekistan etc. It could be customized to mobile jaw crusher too.
How Does A Jaw Crusher Work?
Jaw Crusher machine uses compressive force to break hard stone material, such as granite, basalt, limestone, gold ore,boulders etc. There two vertical manganese jaw plates create a V-shaped cavity called crushing chamber, where the top of the crushing chamber is larger than the bottom.
The moving jaw moves back and forward against the fixed jaw, and material fed from the top chamber is compressed between the two jaws, breaking it into smaller pieces.As the moving jaw moves away from the fixed jaw, the crushed material is discharged from discharge opening at the bottom.
The required rock size is determined by the gap between the jaws.
PE series jaw crusher
| Model |
Feeder Opening Size(mm) |
Max. Feeding Size (mm) |
Outlet adjusting Size(mm) |
Capacity (t/h) |
Motor Power (kw) |
Overall Dimension (mm) |
| PE250x400 | 250x400 | 210 | 25-60 | 5-20 | 15 | 1215x1240x1210 |
| PE400x600 | 400x600 | 350 | 40-90 | 15-60 | 30 | 1700x1750x1680 |
| PE500x750 | 500x750 | 425 | 50-100 | 40-130 | 45 | 2150x1900x1950 |
| PE600x900 | 600x900 | 500 | 60-125 | 90-180 | 55 | 2500x2010x2350 |
| PE750x1060 | 750x1060 | 630 | 60-150 | 110-380 | 110 | 2630x2310x3110 |
| PE900x1200 | 900x1200 | 750 | 95-165 | 220-450 | 132 | 3720x2850x3250 |
| PE1000x1200 | 1000x1200 | 850 | 200-300 | 280-560 | 160 | 3820x2850x3250 |
| PE1200x1500 | 1200x1500 | 1020 | 150-300 | 400-800 | 220 | 4590×3342×3553 |
| PE1500x1800 | 1500x1800 | 1200 | 210-360 | 520-1100 | 280 | 5100x4700x4300 |
PEX series jaw crusher
| Model |
Feeder Opening Size(mm) |
Max. Feeding Size (mm) |
Outlet adjusting Size(mm) |
Capacity (t/h) |
Motor Power (kw) |
Overall Dimension (mm) |
| PEX150x750 | 150x750 | 120 | 10-40 | 5-16 | 15 | 1310x1118x1145 |
| PEX250x750 | 250x750 | 210 | 15-50 | 15-30 | 22 | 1440x1751x1515 |
| PEX250x1000 | 250x1000 | 210 | 15-60 | 15-52 | 30 | 1730x1950x1400 |
| PEX250x1200 | 250x1200 | 210 | 15-60 | 20-60 | 37 | 1730x2150x1400 |
| PEX300x1300 | 300x1300 | 250 | 25-60 | 30-105 | 55 | 2000x2320x1730 |
*The output will vary according to different materials, feed particle size and other factors
